Project Description

TIDAL PRECENSIO

Pre-amplification beyond description. The TIDAL Presencio is nothing less then an ultimate phono and high level pre amplifier for those who want to open the window between the source and the power amps wider then ever before and to find out what was recorded without any loss of detail and without adding any device colouration.

Three isolated true balanced phono inputs in an external deck allow a free configuration for three different tonearms and cartridges.  This is the reference standard of our worldwide praised Preos to a whole new level of performance.

The Presencio LS exists for those without the need for phono input. Retaining all the properties and performance of the Precensio but without MC phono stage.

PRECENSIO GALLERY

Coming Soon.

Coming Soon
  • pure discrete designed dual mono reference line level / reference phono preamplifier with TIDAL minimal-path-technology
  • minimal amplification stage phono moving coil input RCA, adjustable impedance, constant temperature phono board heating system
  • 2 x dual mono powersupply with toroid transformer for the analog audio part
  • 1 x separate toroid transformer powersupply for the control unit
  • 1 x separate toroid transformer powersupply for the DAC power supply
  • 100.000µF stabilisation capacity, ultra fast response with high-grade-long-life-capacitors
  • filtering and regulation system, two-stage EMC-filter
  • TIDAL’s proprietary UPLS volume adjustment: only 1 high precision resistor in each signalpath for level adjustment. Controlled by an electronically and mechanically isolated motordriven ALPS potentiometer-A/D-converter-unit
  • remote control for volume, soft mute
  • pair line inputs RCA (gold plated and teflon isolated), silver wired, pure silver fuses
  • loop-thru function for surround-sound processors with active 1:1 signal forwarding
  • 2 tape outputs RCA
  • 1 pair MC phone input
  • 3 x PCM digital RCA input, optimized for CD reproduction from CD-drives with digital RCA out, perfectly ripped CD’s as FLAC or WAV files (also as high resolution files up to 192kHz) from highend music server with digital RCA out
  • 2 pair fully descrete designed balanced TIDAL-outputmodules XLR OUT (left and right, pair 1 and pair 2)
  • smart remote power management with TIDAL power amplifiers
  • DC-coupled symmetrical Class-A amplifier
  • voltage gain: 10 dB (line mode) 20 dB (phono mode)
  • bandwith: 1Hz – 350 kHz (-3 dB)
  • distortion: < 0.005%
  • noise: 100 dB (0.5 V output voltage)
  • input impedance: 10 kOhms
  • output impedance: < 40 Ohms
  • DC-coupled symmetrical MC-Class-A amplifier: voltage gain: 55 dB (at 1 kHz), noise: > 80 dB (0.5 mV input voltage), input impedance: 10 – 1.2 kOhms, output impedance: 150 Ohms
  • dimensions: 17.3″ x 4,7″ x 15,3″ / 44 cm x 13 cm x 39 cm
  • weight: 70 lbs. / 32 Kg incl. packaging
TIDAL PRESENCIObalanced line stage & phono preamp, remote control & connection cords (3 box)£68,250
 TIDAL PRESENCIO LS Balanced line stage preamp, remote control and connection cords (2 box) £50,960
 Polish sideshigh gloss polished stainless steel side panels+£800/£1200
 Polished fasciahigh gloss polished stainless steel front middle-panel+£1000/£1500
